Electrical Specifications:
Peak Gain: 7 dBi @ 5150 - 5875 MHz
Peak Gain: 4.5 dBi @ 2400 - 2500 MHz
Connector: N-Female
Impedance: 50 Ohm
VSWR: 2.0:1 Max
Polarization: Vertical, Linear
hpbw/horizontal / vertical: 30 degrees @ 2.4GHZ, 15 degrees @ 5 GHz
Maximum power: 2 W
Environmental & Mechanical Characteristics:
Survival wind speed: 216 km/hr
Temperature Range: -40C to +70C
Humidity: 95% @ 55C
Radome color: Gray
Radome material: ABS
Weight: 70 gr
Dimensions: 22 x 183 mm
