ROSE Data server (RDS)

RDS is a high-performance, all-in-one storage, 100G networking, and container platform designed for enterprise environments. Featuring 20 U.2 NVMe storage slots and a special RouterOS Edition for Storage & Compute (ROSE).

Third parties control your data. Should they? Your business, your files, your future – handed over to external providers with unclear policies and unknown risks. Stop relying on the cloud. Own your infrastructure.

Introducing the Rose Data Server (RDS2216) – a high-performance, all-in-one storage, networking, and container platform designed for enterprise environments. Secure, scalable, and under your control.

Why Choose RDS2216?

1. 20 U.2 NVMe storage slots – Ultra-fast, high-density storage for demanding workloads.
2. 100G high-speed networking – 2× 100G QSFP28 ports, 4× 25G SFP28 ports, 4× 10G SFP+ ports, 2× 10G Ethernet ports, and an extra SFF-8644 interface for
3. flexible connectivity.
4. 16-core 2 GHz ARM CPU + 32GB DDR4 RAM – High-performance processing for networking, storage, and virtualization.
5. Massive energy savings – Cut power consumption and heat output while maintaining high performance – an eco-friendly solution for data-heavy environments.
6. Runs RouterOS – The most flexible, modular networking OS. Supports advanced storage capabilities, including exporting block devices over NVMe-TCP, encryption layers, and modular storage configurations for scalable infrastructure. No subscriptions. No paywalls.
7. Container-ready – Run MinIO, Nextcloud, Shinobi, Frigate, and other OCI compliant containers with ease. We’ve added two USB ports for additional devices and further adaptability.
8. Includes dual hot-swappable power supplies – Ensuring uninterrupted operation and quick replacement without unnecessary downtime.

One Device. Endless Possibilities. It’s a breakthrough in flexible networking and storage for the most demanding enterprise environments. Reliable 100-Gigabit connectivity. Ultra-fast NVMe storage support. Containers. Enterprise-grade performance.

No subscriptions. No paywalls. Just pure, future-proof performance.

You buy it – you own it. Forever. That’s a core MikroTik principle.

Specifications

Product code:	RDS2216-2XG-4S+4XS-2XQ
Architecture:	ARM 64bit
CPU:	AL73400
CPU core count:	16
CPU nominal frequency:	2000 MHz
Switch chip model:	98DX4310
RouterOS license:	6
Operating System:	RouterOS v7 (Special ROSE edition)
Size of RAM:	32 GB
Storage size:	128 MB
Storage type:	NAND
MTBF:	Approximately 200'000 hours at 25°C
Tested ambient temperature:	-20°C to 50°C
IPsec hardware acceleration:	Yes
Suggested price:	$1950.00

Powering

Number of AC inputs:	2
AC input range:	100-240
Frequency (Hz):	50-60
Max power consumption:	286 W
Max power consumption without attachments:	105 W
Cooling type:	10 fans

Ethernet

10/100/1000 Ethernet ports:	1
Number of 1G/2.5G/5G/10G Ethernet ports:	2

Fiber

SFP+ ports:	4
Number of 25G SFP28 ports:	4
Number of 100G QSFP28 ports:	2

Peripherals

Serial console port:	RJ45
Number of USB ports:	2
USB Power Reset:	Yes
USB slot type:	USB 3.0 type A
Max USB current (A):	1
Number of M.2 slots:	2

Other

CPU temperature monitor:	Yes
PCB temperature monitor:	Yes
Voltage Monitor:	Yes
Mode button:	Yes

Certification & Approvals

Certification:	CE, EAC, ROHS
IP:	20

Package content

RDS, IEC cord (2x), K-90 fastening kit, Rackmount ears, Small rear support ears, Long rear Rakmount support ears.
